Application environment of LS50 roller can ear
滾輪罐耳結合我國礦山特點為目前運行中的提升容器更換新型滾輪導向裝置提供了便利條件，
廣泛應用于礦山，煤炭等工業生產部門。
Combined with the characteristics of China's mines, the roller can ear provides convenient conditions for the current
operation of the lifting container to replace the new roller guide device, which is widely used in mines, coal and other
industrial production departments.
滾輪罐耳沿罐道運行時，因罐道的設計安裝，會產生接點、彎曲高點，輪頭會受到水平推力作用，
由于支臂架、底座和緩沖器之間的鉸接作用，使緩沖器受壓縮產生反彈力。
How to use LS50 roller can ear
根據滾輪磨損情況，應對滾輪進行調整，方法是松開螺桿鎖緊螺母，轉動螺桿使滾輪靠向罐道，
間隙0～2mm，調好后緊固鎖緊螺母。
According to the wear condition of the roller, the roller should be adjusted by loosening the screw lock nut, turning the screw to make the roller close to the tank channel, with a gap of 0 ~ 2mm, and then tightening the lock nut.
HLS50 roller can ear product parameters
| 【型號】：LS50 | 【承受最大水平力(kN)】 : 45 |
| 【重量(kg)】 : 500 | 【緩沖行程 mm】: 10-14 |
| 分類 | 型號 | 滾輪直徑mm | 最大水平力KN | 緩沖行程mm |
| 單輪 | L25 | 250 | 12 | 10~14 |
| L30 | 300 | 16 | ||
| L35 | 350 | 24 | ||
| L42.5 | 425 | 33 | ||
| L45 | 450 | 35 | ||
| L50 | 500 | 36 | ||
| 雙輪 | LS30 | 300 | 20 | |
| LS35 | 350 | 28 | ||
| LS42.5 | 425 | 42 | ||
| LS45 | 450 | 44 |
Precautions for LS50 roller can ear
滾輪罐耳應定期維護，滾輪罐耳的軸承6個月加注一次潤滑脂，滾輪、支架、彈簧緩沖裝置、底座每年檢查一次，對螺紋、彈簧、軸銷等重新加注潤滑脂。
The roller can ear should be maintained regularly. The bearing of the roller can ear should be filled with grease once every 6 months. The roller, bracket, spring buffer device and base should be inspected once a year. The thread, spring and axle pin should be re filled with grease.
滾輪每半年應加注一次防水潤滑脂，加注量為0.2升；新輪出廠前已加注潤滑脂，請不要再加注。
The roller should be filled with waterproof grease once every half a year, and the filling amount is 0.2L; The new wheel has been filled with grease before leaving the factory, please do not fill it again.
在使用中應每班檢查滾輪工作情況，如發現螺栓松動、滾輪或擺架松曠、復合調整器松曠、滾輪運轉和磨損異常、擺架變形等，應查明原因復原后才能使用。
In use, the working condition of the roller should be checked every shift. If the bolt is loose, the roller or swing frame is loose, the composite adjuster is loose, the roller is abnormal in operation and wear, and the swing frame is deformed, the reason should be found out before use.
如發現質量問題，不得自行拆卸，應與經銷商協商修理或退還，也可直接與本公司聯系。
